Linksys EtherFast BEFSR41W - Manual (Page 12)

2. A username and password prompt will appear. Leave the User Name box
empty and type admin (the default password) in the Password box. Click
OK. (See Figure 5-2.)
3. The Cable/DSL Wireless-Ready Router’s Setup page will appear. (See Figure
5-3.)
Figure 5-2
Figure 5-3
N No otte e:: The
Setup page
shown in this
graphic may
differ from
yours.
EtherFast ® Cable/DSL Wireless-Ready Router with 4-Port Switch
17 16
Chapter 5: Configuring Your
Network with the Cable/DSL
Wireless-Ready Router
Configuring the Cable/DSL Wireless-Ready Router
Now that your Cable/DSL Wireless-Ready Router is wired into your network,
you can begin configuring your system.
Note:If your Windows system supports UPnP, Windows will offer to create a
desktop shortcut to the Router. Click OK to create the desktop icon, then dou-
ble-click on the icon to connect to the Router. Otherwise, connect to the Router
manually, as follows.
1. Open your web browser and type http://192.168.1.1 in the browser’s Address
box. (See Figure 5-1.) This number is the default IP address of your Router.
Press Enter.
N No otte e:: If you have previously enabled an Internet Sharing
Proxy Service on any of your PCs, you must disable it now.
• If you are running Netscape Navigator: Click E Ed diitt >> P Prre effe erre en nc ce e >>
A Ad dv va an nc ce ed d >> P Prro ox xiie es s> and click D Diirre ec ctt C Co on nn ne ec cttiio on n tto o tth he e IIn ntte errn ne ett.
• If you are running Internet Explorer v5 or better, click S Stta arrtt>>
S Se ettttiin ng gs s>> C Co on nttrro oll P Pa an ne ell>> IIn ntte errn ne ett O Op pttiio on ns s>> C Co on nn ne ec cttiio on ns s>>
L LA AN N S Se ettttiin ng gs s. Remove the checks from all three boxes. Click O OK K to
continue.
Figure 5-1
Instant Broadband TM Series
