2 Gbit/s Fibre Channel to PCI Host Adapters vii
Rev. 2.0 Copyright © 2002 by LSI Logic Corporation. All rights reserved.
Contents
Chapter 1
Installing the 2 Gbit/s Host Adapters
1.1 General Description 1-1
1.2 Obtaining Windows NT/Windows 2000 Drivers 1-2
1.3 Quick Host Adapter Installation Procedure 1-2
1.4 Detailed Installation Procedure 1-3
1.4.1 Before You Start 1-3
1.4.2 Inserting the Host Adapter 1-3
Chapter 2
2 Gbit/s Host Adapter Characteristics
2.1 General Description 2-1
2.1.1 Hardware and Software Support 2-2
2.2 Features 2-3
2.2.1 PCI Interface 2-3
2.2.2 FC Interface 2-4
2.3 Physical Environment 2-4
2.3.1 Electrical Characteristics 2-5
2.3.2 Thermal, Atmospheric Characteristics 2-5
2.3.3 Electromagnetic Compliance 2-6
2.3.4 Safety Characteristics 2-6
2.4 Operational Environment 2-6
2.4.1 The PCI Interface 2-6
2.4.2 The FC Interface 2-7
2.4.3 The FC Link Activity/Link Fault LED 2-7
2.5 IEEE Unique Address 2-7
2.6 Physical Characteristics 2-7
2.6.1 LSI40919O Host Adapter Configuration 2-8
2.6.2 LSI40919O Connector and Indicator LED 2-9
