Physical Characteristics
2-21
Ver. 2.0
Copyright © 2002 by LSI Logic Corporation. All rights reserved.
2.6.14 LSI44929H Connectors
The LSI44929H I/O bracket is configured as shown in
. Two
HSSDC connectors are used to connect the adapter channel to the Fibre
Channel subsystem.
Figure 2.14 LSI44929H Connectors
Channel 0
Channel 1
