Job Information
Type:
Calculite
®
HID Downlight
C4T4VM
Page 3 of 4
4½" Aperture, 2pc Vertical, PGJ5 Medium Beam
22W PGJ5 Philips MiniMastercolor CMH Lamp, Lumen Rating = 1650 lms, Aromat Electronic Ballast, CL Finish Trim
39W PGJ5 Philips MiniMastercolor CMH Lamp, Lumen Rating = 3000 lms, Aromat Electronic Ballast, CL Finish Trim
ANGLE MEAN CP LUMENS
0
1184
5
1155
109
10
1089
15
981
275
20
837
25
679
319
30
558
35
466
282
40
305
45
112
104
50
9
55
0
2
60
0
65
0
0
70
0
75
0
0
80
0
85
0
0
90
0
ZONAL LUMENS AND PERCENTAGES
ZONE LUMENS % LAMP %LUMINAIRE
0-30
703
43.28
64.45
0-40
985
60.63
90.28
0-60
1091
67.16
100
0-90
1091
67.16
100
40-90
106
6.53
9.72
60-90
0
0
0
90-180
0
0
0
0-180
1091
67.16
100
1200
900
600
300
LUMINANCE SUMMARY CD. / SQ. M.
ANGLE MEAN CD/SQ M
45
15448
55
30
65
0
75
0
85
0
**EFFICIENCY = 67.2%**
CERTIFIED TEST REPORT NO. 3896FR
SC = .8
CANDLEPOWER DISTRIBUTION
30°
60°
Coefficients of Utilization
Ceiling
80%
70%
50%
30%
Wall
70
50
30
10
50
10
50
10
50
10
0
RCR
Zonal Cavity Method - Effective Floor Cavity Reflectance = 20%
0
.80 .80 .80 .80 .78 .78 .75 .75 .71 .71 .67
1
.77 .75 .74 .72 .74 .71 .71 .69 .68 .67 .64
2
.74 .71 .69 .66 .70 .66 .67 .64 .66 .63 .61
3
.70 .67 .64 .61 .66 .61 .64 .60 .63 .59 .57
4
.67 .63 .60 .57 .62 .57 .61 .56 .60 .56 .54
5
.64 .59 .56 .53 .59 .53 .58 .53 .57 .52 .51
6
.62 .56 .53 .50 .56 .50 .55 .50 .54 .49 .48
7
.58 .53 .49 .47 .53 .46 .52 .46 .51 .46 .45
8
.56
.5 .46 .44 .49 .43 .49 .43 .48 .43 .42
9
.53 .47 .43 .41 .46 .41 .46 .40 .45 .40 .39
10
.50 .44 .40 .38 .44 .38 .43 .38 .43 .38 .37
LUMINAIRE INPUT WATTS = 25
ANGLE MEAN CP LUMENS
0
3222
5
3023
282
10
2543
15
1975
563
20
1453
25
1032
493
30
742
35
559
356
40
408
45
178
152
50
20
55
4
7
60
3
65
2
2
70
1
75
0
0
80
0
85
0
0
90
0
ZONAL LUMENS AND PERCENTAGES
ZONE LUMENS % LAMP %LUMINAIRE
0-30
1337
44.59
72.13
0-40
1694
56.47
91.34
0-60
1852
61.75
99.89
0-90
1854
61.82
100
40-90
160
5.35
8.66
60-90
2
0.07
0.11
90-180
0
0
0
0-180
1854
61.82
100
750
1500
2250
3000
LUMINANCE SUMMARY CD. / SQ. M.
ANGLE MEAN CD/SQ M
45
24647
55
605
65
404
75
65
85
0
**EFFICIENCY = 61.8%**
CERTIFIED TEST REPORT NO. 3910FR,
SC = .6
CANDLEPOWER DISTRIBUTION
30°
60°
Coefficients of Utilization
Ceiling
80%
70%
50%
30%
Wall
70
50
30
10
50
10
50
10
50
10
0
RCR
Zonal Cavity Method - Effective Floor Cavity Reflectance = 20%
0
.74 .74 .74 .74 .72 .72 .69 .69 .66 .66 .62
1
.71 .69 .68 .67 .68 .66 .66 .64 .63 .62 .59
2
.68 .66 .64 .62 .65 .61 .63 .60 .61 .59 .57
3
.65 .62 .60 .58 .61 .58 .60 .57 .59 .56 .54
4
.63 .59 .57 .55 .59 .54 .57 .54 .56 .53 .52
5
.61 .56 .53 .51 .56 .51 .55 .51 .54 .50 .49
6
.58 .54 .51 .49 .53 .48 .52 .48 .52 .48 .47
7
.56 .51 .48 .46 .51 .46 .50 .46 .49 .45 .44
8
.54 .49 .46 .44 .48 .43 .48 .43 .47 .43 .42
9
.51 .46 .43 .41 .46 .41 .45 .41 .45 .41 .40
10
.49 .44 .41 .39 .44 .39 .43 .39 .43 .39 .38
LUMINAIRE INPUT WATTS = 25
750
1500
2250
3000
300
