Page 53: Figure 28
Operation
47
Active Cycle Time in place of Accumulated Battery Time, and shows Active Battery AH and Active Battery
kWH instead of accumulated values.
Figure 27 Battery Cycle Monitoring Summary Screen
Figure 28 shows a typical detail screen for the 91-240 Seconds Discharge category. This information can be col-
lected remotely, through the optional communications board and modem, by a remote terminal or a personal
computer equipped with a modem and communications program. See 3.1.14 - Communication Interfaces for
more information.
Figure 28 Typical Data on Discharge Cycles of 91 to 240 Seconds Duration During the Recording
Period
NOTE
This information is applicable to systems with separate batteries for each module. If
the modules share a common battery, select one module to do the monitoring and
disregard the other(s).
7
15 min. 32 sec.
71
34
25°C / 77°F
Total No. of Cycles . . . . . . . . . . . . .
Accumulated Battery Time . . . . . . .
Accumulated Battery AH . . . . . . . .
Accumulated Battery KWH . . . . . . .
Battery Temperature . . . . . . . . . . . .
Battery Cycle Monitoring Summary
EXIT
SELECT :
EXIT
Event
Date
Time
Duration
Min. Volt
Max. Amp Start KW Start Temp
15
4/12/95
10:31
235
477
110
70
68
12
3/25/95
20:21
98
479
97
37
65
9
3/13/95
7:35
139
467
173
69
67
5
2/07/95
17:22
199
478
95
40
70
2
11/24/94
12:33
95
477
83
39
69
Total
91-240 se c. Cycl
5
CURSOR UP
CURSOR DOWN
CHOOSE
UP :
DOWN :
SELECT :
