Present status, Figure 23, Present status report screens – Liebert Series 600T User Manual
Page 48
42
Operation
Present Status
The Present Status screen shows the current status of the UPS system (SCC) or module. This screen displays any
alarm messages that are present and the values of the metered parameters for each cabinet. Battery values are dis-
played only at the UPS modules.
Each update sequence (every 4 milliseconds) is called a frame. The frame number is displayed in the upper right
corner. The Present Status screen display is updated every two seconds.
Battery Time Remaining (in minutes) is displayed on the module screens during a battery discharge. The value is
on the Battery Volts line in the TIME column (far right side of the screen). For the first two minutes of discharge,
the Rated Time Remaining is displayed. After that, the Calculated Time Remaining is displayed, and updated
every six seconds.
All the information on this screen, including Battery Time Remaining, is available to a local terminal or modem
through the communications ports provided in the Series 600T UPS. Refer to Table 3 in this manual for key-
board commands to use with the communication ports.
Figure 23 Present Status Report Screens, SCC (above) and Module
