Appendix C: Adding Cameras
49
Appendix C: Adding Cameras
The system comes with a camera that has already been paired to the wireless receiver.
The Pairing Function assigns each camera to a different channel on the wireless receiver (up to
four cameras), and is necessary for configuring additional cameras. By default, the camera
included with the system appears on channels 1 on the wireless receiver.
NOTE: It is highly recommended to pair the cameras to the receiver before permanently
mounting the cameras.
To pair an additional camera:
1. Connect the new camera to a power outlet. DO
NOT permanently mount the camera.
2. Press MENU on the wireless receiver or remote
control.
3. From the Main Menu, select Pairing and press the
Enter/OK button.
4. Select Camera 2, Camera 3, or Camera 4 and
press the Enter/OK button.
NOTE: By default, the camera included with your
system is paired as Camera 1 (channel 1).
5. Following the on-screen prompt, press the Pair
button on the rear panel of the camera. You have
30 seconds to press the PAIR button on the
camera. Once paired, the camera will be
immediately displayed on-screen.
NOTE: If you do press the Pair button on the
camera during the 30 second pairing window,
repeat steps 2~5 to try the pairing process again.
Once the camera is paired you can permanently
mount the camera to a desired location.
Figure 13.1 Pairing screen
Please Press
Pair Key on
Camera side
30
C C a a m m 2 2
At the pairing screen, you have 30
seconds to press the PAIR button on the
rear panel of the camera.
Figure 13.0 Pairing menu
Figure 13.2 Press “Pair” on the back of the
camera
