Lincoln Electric INVERTEC SVM101-B - Manual (Page 57)

V300-I
TROUBLESHOOTING & REPAIR
F-27 F-27
Re
tu
rn
t
o Se
ct
io
n T
O
C
Re
tu
rn t
o Se
ct
io
n T
O
C
Re
tu
rn t
o Se
ct
io
n T
O
C
Re
tu
rn t
o Se
ct
io
n T
O
C
Re
tu
rn t
o Ma
st
e
r T
O
C
Re
tu
rn t
o Ma
st
e
r T
O
C
Re
tu
rn t
o Ma
st
e
r T
O
C
Re
tu
rn t
o Ma
st
e
r T
O
C
SWITCH BOARD TEST (CONT.)
Apply Positive Apply Negative
Test Probe to Test Probe to
Terminal
Terminal Test Result Conclusion Repair Action Next Procedure Notes
1/8 12 Greater than OK None Continue
1K ohm
Less than Shorted Replace both Snubber Test
100 ohms Switch Boards
12 1/8 Less than OK None Continue
100 ohms
Greater than Open Replace both Snubber Test
1K ohm Switch Boards
9 4/5 Greater than OK None Continue
1K ohm
Less than Shorted Replace both Snubber Test
100 ohms Switch Boards
4/5 9 Less than OK None Continue
100 ohms
Greater than Open Replace both Snubber Test
1K ohm Switch Boards
1/8 9 Less than OK None Continue
100 ohms
Greater than Open Replace both Snubber Test
1K ohm Switch Boards
9 1/8 Greater than OK None Continue
1K ohm
Less than Shorted Replace both Snubber Test
100 ohms Switch Boards
12 4/5 Less than OK None Continue
100 ohms
Greater than Open Replace both Snubber Test
1K ohm Switch Boards
4/5 12 Greater than OK None Continue
1K ohm
Less than Shorted Replace both Snubber Test
100 ohms Switch Boards
NOTE: K ohm = ohm reading multiplied by 1000.
NOTE: Always make sure that Switch Boards are changed in matched pairs. Never mix an old style (different
part number) Switch Board with a newer style.
TABLE F.2
SWITCH BOARD RESISTANCE CHECKS
