Lincoln Electric INVERTEC SVM101-B User Manual
Invertec v300-i, Svm101-b, Service manual

INVERTEC V300-I
SVM101-B
January, 2007
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However,
your overall safety can be
increased by proper installation
. . . and thoughtful operation on
your part. DO NOT INSTALL,
OPERATE OR REPAIR THIS
EQUIPMENT WITHOUT READ-
ING THIS MANUAL AND THE
SAFETY PRECAUTIONS CON-
TAINED THROUGHOUT. And,
most importantly, think before
you act and be careful.
SERVICE MANUAL
For use with machines having Code Number : 9825 THRU 10450
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
• World's Leader in Welding and Cutting Products •
Copyright © 2007 Lincoln Global Inc.
RETURN TO MAIN MENU
Document Outline
- Master Table of Contents
- Safety
- Section A - Installation
- Section B - Operation
- Section C - Accessories
- Section D - Maintenance
- Section E - Theory of Operation
- Section F - Troubleshooting and Repair
- Symptoms
- Major physical or electrical damage is observed when cover wraparound is removed.
- Machine is dead — no output — no fan — no display.
- No output but fan operates and the meter display is on.
- No output or reduced output the first time power is applied to machine.
- Output turns on momentarily, then switches off and repeats cycle.
- Remote output control not functioning. Machine performs well on LOCAL control.
- No ouput. Main fuses open, indicating excessive current draw.
- Machine does not produce more than 250 amps on meter (while welding) when connected to 3-phase supply.
- Machine does not produce more than 250 amps on meter (while welding) while connected to singlephase supply
- Machine operates okay at 230 VAC or lower. No output at 380 VAC or higher
- Meter reads low voltage (1-2 VDC), and output is extremely low or no output.
- Poor welding, weld settings drift, or output power is low.
- Welding “too hot”. Actual weld current is considerably higher than display indicates.
- Poor stick electrode performance. Arc pops out.
- Machine makes “squealing” noise while under load when welding. Output power is low (less than 20 VDC on meter @ 100 amps). Input voltage 230 VAC or lower.
- Section G - Electrical Diagrams
