Commercial Pool Heaters
GLOSSARY
POWER SUPPLY
120VAC/60Hz/1PH power connects to black (line) and white
(neutral) wires located within an electrical wiring box located on
the left side of the pool heater. A green chassis grounding wire is
also provided for connection to earth ground.
ON/OFF ROCKER SWITCH
The black line voltage wire runs directly to a single pole, single throw
On/Off rocker switch located behind the front cover accessible by a
knurled knob. Turning ON the rocker switch delivers line voltage to
the low voltage transformer and ignition module.
Note: The On/Off switch does not provide for disconnection of
power being supplied to any remotely connected devices that may be
connected to the pool heater (i.e. pumps, louvers, power venters, etc.).
As such, it may be necessary to locate and turn “OFF” power to these
items before attempting to service the pool heater.
LOW VOLTAGE SUPPLY TRANSFORMER
A 120VAC to 24VAC transformer located within the control panel
provides 24VAC/60Hz to many of the components located on the
pool heater. One of its 24VAC outputs (blue) is connected to a
circuit breaker and the other (yellow) is connected to chassis
ground.
24VAC CIRCUIT BREAKER
A circuit breaker is provided for protection of the low voltage supply
transformer from overloads and short circuits. The breaker is
located inside the pool heater on the right rear of the control panel.
Power from this breaker goes to the temperature controller, ignition
module and various other components and/or options on the pool
heater. When tripped, all factory-installed 24VAC components will
lose their 24VAC power.
MANUAL RESET HIGH-LIMIT THERMOSTAT
A manual reset high limit thermostat is provided as backup for the
auto reset high limit. This is an adjustable dial, bulb-capillary style
thermostat that will trip and require resetting should water
temperature exceed its settings. When tripped, all controls remain
powered, but 24VAC is prevented from being delivered to the
ignition module’s thermostat input.
EMS/SEQUENCER/REMOTE AQUASTAT
TERMINALS
The EMS/sequencer/remote aquastat terminals are provided for
connection of the pool heater to an external energy management
system or sequencer and are located along the top edge of the
terminal strip located within the electrical wiring box. In addition
to providing a means to externally fire the pool heater, these
terminals also provide for remote shutdown by routing through dry
contacts from external devices. Connection of the external dry
contacts to these terminals requires the removal of one or more
factory-installed jumpers located on the terminal strip.
SAFETY DEVICE TERMINALS
The safety device terminals ensure that no power can be delivered
to the ignition module unless factory/field-installed safety devices
such as flow switches and gas pressure switches are closed. These
safety device terminals are located below the
EMS/Sequencer/Remote Aquastat terminals located within the
electrical wiring box. Two types of connections are offered:
Continuous terminals provide for connection of safety devices that
are desired to be constantly monitored. Intermittent terminals are
provided for devices that are only monitored during a “call for heat”
cycle. Connection to either of these terminals requires the removal
of a factory-installed jumper located on the terminal strip.
TEMPERATURE CONTROLLER
(Operator) A single-stage temperature controller is provided on the
pool heater and it serves to maintain a user selectable temperature
set point. In addition to maintaining a set point, it can provide for
desired differential setting. Ultimately, the temperature controller
delivers 24VAC to the ignition module and pressure switch when it
senses heat mode is desired.
IGNITION MODULE
(Controlled by Temperature Controller)
One ignition module is provided on the pool heater. Upon sensing
the 24VAC delivered to it by the temperature controller, the ignition
module checks for a shorted pressure switch and then, provided the
air switch isn’t shorted, supplies 120VAC to its blower output relay
and waits for a pressure switch signal.
BLOWERS
(Controlled by Ignition Module and Relay Board)
Two blowers serve to provide combustion air to the pool heater.
Both blowers operate in tandem anytime the ignition module is
given a call for heat signal.
PRESSURE SWITCH
(Activated by Blower Turning On)
One pressure switch is provided to monitor its On/Off operation.
Upon a call for heat, 24VAC is delivered to the pressure switch. If
the blower generates adequate air pressure, the pressure switch
closes to deliver 24VAC to the ignition module’s pressure switch
monitoring input terminal.
PREPURGE
(Ignition Module Function)
Once the ignition module sees a 24VAC input from its pressure
switch, it runs the blowers for approximately 15 seconds in order
to purge the combustion chamber of any unburned fuel/air
mixture.
