CONTENTS
I
NTRODUCTION
. . . . . . . . . . . . . . . . . . . . . . . . . .2
S ERVICE I NFORMATION . . . . . . . . . . . . . . . . . . . .2
P ARTS AND C ONTROLS . . . . . . . . . . . . . . . . . . . . .3
S AFETY P RECAUTIONS . . . . . . . . . . . . . . . . . . . . .4
A SSEMBLING THE X TRA E DGER . . . . . . . . . . . . . .8
F UEL M IX AND F UELING . . . . . . . . . . . . . . . . . . .8
S TARTING AND S TOPPING I NSTRUCTIONS . . . . . .10
O PERATING I NSTRUCTIONS . . . . . . . . . . . . . . . .11
A IR AND F UEL F ILTER M AINTENANCE . . . . . . .13
E NGINE I DLE S PEED A DJUSTMENT . . . . . . . . . .13
C UTTER B LADE R EPLACEMENT . . . . . . . . . . . . .14
L UBRICATION OF G EARS . . . . . . . . . . . . . . . . . .14
C HECKING THE S PARK P LUG . . . . . . . . . . . . . . .15
C HECKING THE M UFFLER . . . . . . . . . . . . . . . . .15
T ROUBLESHOOTING T IPS . . . . . . . . . . . . . . . . . .16
P ARTS L IST . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
P ARTS B REAKDOWN . . . . . . . . . . . . . . . . . . . . 19
E NGINE P ARTS L IST . . . . . . . . . . . . . . . . . . . . .20
E NGINE P ARTS B REAKDOWN . . . . . . . . . . . . . . .21
B ODY W ORKSHOP M ANUAL . . . . . . . . . . . . . . . .22
W ARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
I NTRODUCTION
This Manual contains operating, assembling,
safety and maintenance instructions for the
Little Wonder
Gasoline Powered Xtra Edger.
This professional edging machine was designed to
the highest standards to ensure you many hours of
uninterrupted service.
Pay special attention to the safety precautions
outlined on pages 4 to 7. Allow only persons who
understand this Manual to operate the Xtra Edger.
To receive maximum performance and satisfaction
from your Xtra Edger, it is important that you read
and understand the maintenance and safety
precautions before using the edger. Contact your
Little Wonder dealer or the Little Wonder distribu-
tor in your area if you do not understand or cannot
carry out any of the instructions in this Manual.
S ERVICE I NFORMATION
Contact your authorized Little Wonder
dealer for service.
WARNING
As with any power tool, some special
safety precautions must be observed
to reduce the risk of personal injury.
Careless or improper use may cause
serious or even fatal injury.
▲
!
▲
!
SAFETY WARNINGS
THE PURPOSE OF SAFETY WARNING AND NOTES IN THIS MANUAL
IS TO ATTRACT YOUR ATTENTION TO POSSIBLE DANGERS AND THE
EXPLANATIONS WITH THEM DESERVE YOUR CAREFUL ATTENTION
AND UNDERSTANDING. THE SAFETY WARNINGS IN THIS MANUAL AND
ON THE XTRA EDGER DO NOT, BY THEMSELVES, ELIMINATE ANY
DANGER. THE INSTRUCTIONS OR WARNINGS THEY GIVE ARE NOT
SUBSTITUTES FOR PROPER ACCIDENT PREVENTION MEASURES.
▲
!
▲
!
▲
!
WARNING:
Failure to obey a
safety warning can
result in injury to
yourself and others.
NOTE:
Advises you of information
or instructions vital to the
operation or maintenance
of the equipment.
!
2
