DUAL LAMP MODULE
NOTE
The SPRING in the DUAL LAMP MODULE has to be mounted without tension between the
MIRROR and the MOTOR.
Lubrication
Use the lubricant BARRIERTA L 25 DL (50g) No. 558 1960. Grease all arrow marked spots.
SPRING
MOTOR
figure 4-34
MECHANISM
FRAME
figure 4-35
SM2547-1 Service Manual
Kodak AG, Stuttgart 4-29 03/98
