If the SHUTTER has to be replaced and the COVER MECHANISM FRAME is provided with the small recess,
the SHUTTER has to be bent first. Otherwise it might touch the COVER MECHANISM FRAME.
SHUTTER
COVER MECHANISM FRAME
GROOVE
figure 4-20
SM2547-1
