DUAL LAMP MODULE (Extra Bright)
1 . Remove the LAMP MODULE from the PROJECTOR.
2 . Lift the EJECTOR LEVER . The defective LAMP will eject from the LAMP SOCKET ASSEMBLY.
3 . Remove the CLIP and the CONDENSER LENS.
EJECTOR
LAMP SOCKET
ASSEMBLY
LAMP
LABEL
EXTRA BRIGHT
SCREW (3)
WASHER (2)
figure 4-30
CLIP
CONDENSER LENS
figure 4-31
Service Manual SM2547-1
03/98 4-26 Kodak AG, Stuttgart
