BUTTONS and COVER PLATES
1 . Remove the UPPER HOUSING. See page 4-1.
2 . Remove the 3 BUTTONS.
3 . Remove the small COVER PLATE.
4 . Loosen the HOLDING CLIP and remove the large COVER PLATE.
5 . If needed, change the 5 BUTTONS.
6 . If necessary, replace the WINDOW and/or MODEL LABEL.
Model 9020
CORPORATE SYMBOL
WINDOW
MODEL LABEL
figure 4-2
BUTTONS (5)
BUTTONS (3)
small COVER PLATE
large COVER PLATE
figure 4-3
Service Manual SM2547-1
03/98 4-2 Kodak AG, Stuttgart
