23
PARTS LIST
MODEL NO.: CH7630SQB
CH7636SQB
CH7642SQB
CH7648SQB
Body Components
NO. DESCRIPTION MODEL/SIZE PART NO.
1 Screws (3/16 x 3/8 ) CH176-1
2 Hood Casing CH176-2
3 Hood-Mounting Bracket CH176-3
4 Screws (3/16 x 3/8 ) CH176-1
5 Stainless Steel Oil Tunnel CH176-4
6 Blower Assembly CH176-5
7 Halogen Light Panel CH176-6
8 Gasket CH176-7
9 Screws (3/16 x 3/8 ) CH176-1
10 Halogen Light CH176-9
11 Gasket CH176-8
12 Stainless Steel Spacer
A
B
C CH7636SQB CH176-11
CH7642SQB CH176-12
CH7648SQB CH176-18
13 Baffle Filter CH176-13
14 Baffle Handle CH176-14
15 Electrical Assembly CH176-15
16 Screws (3/16 x 3/8 ) CH176-1
17 Wiring Box CH176-16
18 Screws (3/16 x 3/8 ) CH176-1
19 Switch Assembly CH176-17
20 Screws (3/16 x 3/8 ) CH176-1
21 Board CH176-18
22 Screws (3/16 x 3/8 ) CH176-1
