Technical Appendix
49
Channel and frequency table for L standard (frequency in MHz)
VHF UHF UHF
01 80.75 21 21 471.25 46 46 671.25
* LB 02 55.75 22 22 479.25 47 47 679.25
* LC 03 60.50 23 23 487.25 48 48 687.25
* LC1 04 63.75 24 24 495.25 49 49 695.25
L1 05 176.00 25 25 503.25 50 50 703.25
L2 06 184.00 26 26 511.25 51 51 711.25
L3 07 192.00 27 27 519.25 52 52 719.25
L4 08 200.00 28 28 527.25 53 53 727.25
L5 09 208.00 29 29 535.25 54 54 735.25
L6 10 216.00 30 30 543.25 55 55 743.25
11 308.75 31 31 551.25 56 56 751.25
12 441.75 32 32 559.25 57 57 759.25
13 861.75 33 33 567.25 58 58 767.25
K
1
4 14 175.25 34 34 575.25 59 59 775.25
K
1
5 15 183.25 35 35 583.25 60 60 783.25
K
1
6 16 191.25 36 36 591.25 61 61 791.25
K
1
7 17 199.25 37 37 599.25 62 62 799.25
K
1
8 18 207.25 38 38 607.25 63 63 807.25
K
1
9 19 215.25 39 39 615.25 64 64 815.25
20 223.25 40 40 623.25 65 65 823.25
41 41 631.25 66 66 831.25
42 42 639.25 67 67 839.25
43 43 647.25 68 68 847.25
44 44 655.25 69 69 855.25
45 45 663.25 70 70 863.25
Special channels
S01 S01 120.00 S21 S21 280.00
S02 S02 128.00 S22 S22 288.00
S03 S03 136.00 S23 S23 303.25
S04 S04 144.00 S24 S24 315.25
S05 S05 152.00 S25 S25 327.25
S06 S06 160.00 S26 S26 33925
S07 S07 168.00 S27 S27 351.25
S08 S08 176.00 S28 S28 363.25
S09 S09 184.00 S29 S29 375.25
S10 S10 192.00 S30 S30 387.25
S11 S11 200.00 S31 S31 399.25
S12 S12 208.00 S32 S32 411.25
S13 S13 216.00 S33 S33 423.25
S14 S14 224.00 S34 S34 435.25
S15 S15 232.00 S35 S35 447.25
S16 S16 240.00 S36 S36 459.25
S17 S17 248.00
S18 S18 256.00
S19 S19 264.00
S20 S20 272.00
Video and audio assessment and level measurement of the audio carrier
are not possible for the channels marked with *.
The channel, display on the MSK 24 and frequency are shown in the table.
