Overview of the keyboard commands
13
Overview of the keyboard commands
Button Brief description of the function for
SAT TV FM
SAT/TV Switch-over to TV reception Switch-over to SAT reception Switch-over to SAT reception
- Decrease current values
+ Increase current values
0...9 Enter numbers
./S
Decimal point for
numerical entries
•
Decimal point for
numerical entries
•
Call up special channel
Decimal point for
numerical entries
ENTER Confirm numerical entries
2ndF +
button
Call up second command level
FM Switch-over to FM
Sat-Ctrl
Call up the DISEqC/
V-SEC menu / LNB
LNB
LNB voltage menu and
current measurement
No function
Ch-Freq No function
•
Call up the frequency menu
•
Switch-over from channel to
frequency display and vice versa.
Std DVB/analogue switch-over
•
DVB/analogue switch-over
•
Standard switch-over
SC (Subcarrier) Audio carrier menu
Scan Search for a satellite irrelevant of frequency
No function
Level Switch on level-dependent acoustic signal with bar display
Spect Spectrum analysis
Setup Define receiver settings
Keyboard of MSK 24:
See above for details
7 8 9
4 5 6 1 2 3
0 ./S
4 5 6
1 2 3
Sat-Ctrl
Level
Ch-Frq
LNB
SC
Scan
MHz
2ndF Spect Setup Std
Sat/TV +
FM
