Sat measurement
31
Overview of commands in Data Byte
An appropriate data byte only needs to be sent when the command byte
requires data byte(s). You can see this in the above command byte table.
You can find out which data byte has to be sent to which command byte
in the data sheets for the relevant receiver.
Orbit
position
Switch position
H/V
Switch position
LNB
Data
byte
V Lo F0
1 V Hi F1
H Lo F2
H Hi F3
V Lo F4
2 V Hi F5
H Lo F6
H Hi F7
V Lo F8
3 V Hi F9
H Lo FA
H Hi FB
V Lo FC
4 V Hi FD
H Lo FE
H Hi FF
Simple Tone Burst DiSEqC
A simplified form of DiSEqC control is the Simple Tone Burst DiSEqC
procedure. In this Simple DiSEqC two switching states are possible: tone
burst and data burst.
Overview of commands in Simple DiSEqC
[2ndF] [SAT-CTRL] Call up the SAT–CTRL menu
[3] Call up the DiSEqC menu
[0] Enter tone burst
[1] Enter data burst
[ENTER] Send the command string
Exit the DiSEqC menu by pressing [2ndF] twice.
