TV measurement
35
Channel Display and Entering Channel
To measure the level of a received TV signal, you must first enter the
desired channel.
The following channels can be set:
•
Band I / III CH 01 to CH 12 in the 7 MHz raster
•
Band IV / V CH 21 to CH 70 in the 8 MHz raster
•
Special channel S 01 to S 20 in the 7 MHz raster
•
Special channel S 21 to S 41 in the 8 MHz raster
The information refers only to the factory-preset B/G standard. You can
find information for other standards in the Technical Appendix.
Overview of commands in Entering Channel (TV)
[SAT/TV] Switch over to TV reception
[0]...[9] Enter the channel
[./S] Switch to special channel
[+] and [-] Alter the channels gradually
Example
Enter channel S11:
Press [./S] [1] [1].
LC display:
•
Special channel: S 11
•
Level: 62.5 dBìV
•
Mode: TV
Note
Make sure that the correct standard has been set. The B/G standard is
the default setting.
CH:S.11. TV
LEV: 62.5dBuV
