Top View
Side View
560/750 System Diagrams
4
Slide Gate
Auto Focus
Focus Knob
Caution Label
Slide Projector
Slide Tray
Lamp House
Projection Lens
Power Supply Unit
Operating Switch
Warning Label
Adjustable Screw Leg
Power Switch
Power Lamp
Rear Side
Caution Label
Slide Reverse Button
Slide Foward Button
Slide Select Button
Auto Focus
