Kodak 9020/CINE - Manual (Page 41)

Power Regulation Board Power Module
Fuse
Voltage Selector
Switch
L
N
)
)
)
Black
Red
White
Gray
Regulator
Regulator
Line
Filter
Zero Cross
Circuit
10V
26V
Blue
12V DC
5V DC
VSS
26V AC_FL
Zero_Cross
36V DC_12P
36V DC
15V DC
Triac
Relay
Lamp1
Lamp2
Neutral
VSS
240
230
220
120
91
82
1.25A
2A
USA 2.8A
Economy
Normal
Triac
Relay
figure
3-3
SM
2547
-1
Service Manual
Kodak AG,
Stuttgart
3-5
03/98
