Technical Data
9
Technical Data
Power supply
Mains operation
230 VAC, 50/60 Hz
Battery operation Lead Battery 12 V/3.4 Ah
Dimensions Width 260 mm, Height 90 (120) mm, Depth 165 mm
incl. accessories (plus case)
Weight ca. 4.5 kg (incl. case)
Safety standards CE mark
Protection class II
VDE EN 61010
Display TFT screen, LCD alpha numeric, 2x16 characters, Bargraph
display, backlit
Temperature range +5 C to +45 C
Frequency range SAT 920 MHz...2150 MHz
TV 48 MHz...858 MHz
FM 88 MHz...108 MHz (48 MHz...858 MHz)
Channel configuration TV B standard 7 MHz
D/G/I/K standard 8 MHz
M/N/M1 standard 6 MHz
Frequency tuning SAT 0.125 MHz graduations
TV 50 kHz graduations
FM 50 kHz graduations
Measurement error SAT Max. ±2 dB
TV/FM Max. ±2 dB
RF input BNC 75 Ω coaxial socket
RF input reducer 0 – 60 dB in 4 dB graduations
Level measurement range 30–120 dBµV
Measurement bandwidth SAT 6 MHz
SAT DVB 6 MHz
TV 250 kHz TV/DVB 6 MHz
FM 250 kHz
Measuring detector SAT Average value display
TV Maximum value display
FM Average value display
Voltage standing wave ratio > 6 dB
FM threshold SAT < 9 dB
Audio-IF bandwidth SAT 230 kHz/150 kHz
TV 230 kHz
FM 230 kHz
Audio Deemphasis SAT 50 µs
TV/FM 50 µs
Audio processing SAT FM audio processing 5.0 MHz…8.99 MHz in 10-kHz graduations
TV FM and Nicam in quasi-parallel audio mode
AM in parallel audio mode (L standard only)
