Kathrein MSK 25 - Manual (Page 49)

Technical Appendix
49
Channel Tables
Channel Table and Frequency Table B/G Standard (frequencies in MHz)
VRF-CCIR URF-CCIR URF-CCIR
Pilot frequency 01 80.15 21 21 471.25 46 46 671.25
E2 02 48.25 22 22 479.25 47 47 679.25
E3 03 55.25 23 23 487.25 48 48 687.25
E4 04 62.25 24 24 495.25 49 49 695.25
E5 05 17.25 25 25 503.25 50 50 703.25
E6 06 182.25 26 26 511.25 51 51 711.25
E7 07 189.25 27 27 519.25 52 52 719.25
E8 08 196.25 28 28 527.25 53 53 727.25
E9 09 203.25 29 29 535.25 54 54 735.25
E10 10 210.25 30 30 543.25 55 55 743.25
E11 11 217.25 31 31 551.25 56 56 751.25
E12 12 224.25 32 32 559.25 57 57 759.25
A 13 53.75 33 33 567.25 58 58 767.25
B 14 62.25 34 34 575.25 59 59 775.25
C 15 82.25 35 35 583.25 60 60 783.25
D 16 175.25 36 36 591.25 61 61 791.25
E 17 183.75 37 37 599.25 62 62 799.25
F 18 192.25 38 38 607.25 63 63 80725
G 19 201.25 39 39 615.25 64 64 815.25
H 20 210.25 40 40 623.25 65 65 823.25
41 41 631.25 66 66 831.25
42 42 639.25 67 67 839.25
43 43 647.25 68 68 847.25
44 44 655.25 69 69 855.25
45 45 663.25
LSB/USB ESB
S01 S01 105.25 ES21 S21 303.25
S02
1) S02 113.00 ES22 S22 311.25
S03
1) S03 121.00 ES23 S23 319.25
S04 S04 126.25 ES24 S24 327.25
S05 S05 133.25 ES25 S25 335.25
S06 S06 140.25 ES26 S26 343.25
S07 S07 147.25 ES27 S27 351.25
S08 S08 154.25 ES28 S28 359.25
S09 S09 161.25 ES29 S29 367.25
S10 S10 168.25 ES30 S30 375.25
S11 S11 231.25 ES31 S31 383.25
S12 S12 238.25 ES32 S32 391.25
S13 S13 245.25 ES33 S33 399.25
S14 S14 252.25 ES34 S34 407.25
S15 S15 259.25 ES35 S35 415.25
S16 S16 266.25 ES36 S36 423.25
S17 S17 273.25 ES37 S37 431.25
S18 S18 280.25 ES38 S38 439.25
S19 S19 287.25 ES39 S39 447.25
S20 S20 294.25 ES40 S40 455.25
ES41 S41 463.25
1)
In the FRG the special DVB-C channels S02 and
S03 were allocated with a bandwidth of 8 MHz. The
center frequencies now are: S02 = 113 MHz and S03
= 121 MHz.
Channel raster: 7 MHz for VHF and LSB/USB - 8 MHz for UHF and ESB
Find channels, display indications on the MSK 25 and frequencies, all on the table
