TV measurement

Channel display and channel entry

You first have to set the required channel to be able to measure the level
of a TV reception signal. The following channels may be set:

• Band /III CH 01 to CH 12 in 7 MHz raster
• Band IV/V CH 21 to CH 70 in 8 MHz raster
• Special channel S 02 to S 03 in 8 MHz raster
• Special channel S 04 to S 20 in 7 MHz raster
• Special channel S 21 to S 41 in 8-MHz raster
This information applies only for the factory-set B/G standard. Please find
more information on further standards in the technical appendix.

TV Channel Setting Menu

[SAT/TV]

Changing over to TV reception

[0] bis [9] Setting

channel

[./S]

Changing over to special channel

[+] und [-]

Varying channels stepwise

Example

Setting channel S11:

Press [./S] [1] [1].

LC display:

• Special channel: S 11
• Level: 62,5 dBµV
• Mode: TV analog

Note

Make sure that the correct standard has been set. B/G standard is
factory-set.

CH:S.11.

LEV: 62,5dBuV A

✐

☞
