TV measurement

Standard Change-Over

In TV mode, the MSK 25 can measure the following standards:

• B/G standard
• L standard
• D/K standard
• I standard
• M/N standard
• M1 standard (Japan)

Standard Change-Over TV Menu

[2ndF] [STD] Calling up standard change-over menu

[0]

Addressing standard menu

[0] bis [6]

Selecting standard

Example

Calling upB/G analogue standard:

Press [2ndF] [STD].

LC display:

• 1 = Analogue reception
• 2 = DVB-C reception
• 3 = DVB-T reception (if this option is provided)
• 0 = standard menu

Press [0].

The following menu is displayed:

• 1 = B/G standard- 2 = L standard - 3 = D/K standard etc.

Standard menu

Press [1]. The instrument is now set for analogue reception in the B/G
standard

Note

Please note that the selected standard will be retained after the
instrument has been switched off.

✐

1=ANALOG 3=DVBT
2=DVBC 0=Std.

1=BG 2=L 3=DK
4=I 5=MN 6=M1

☞
