Expansion Slot Connectors
Your computer comes with industry standard IBM compatible
expansion slots. There are eight AT and XT-style expansion slot
connectors mounted on the back plane board. The charts
below show the pin numbering on the expansion slot
connectors.
Expansion Slot Connector Pinouts:
Pin l/O
# Type:
A-l Input
A-2 l/O
A-3 I/O
A-4 I/O
A-5 l/O
A-6 I/O
A-7 I/O
A-8 I/O
A-9 I/O
A-10 Input
A-11 output
A-12 I/O
A-13 I/O
A-14 I/O
A-15 I/O
A-16 I/O
A-17 l/O
A-18 I/O
A-19 l/O
A-20 I/O
A-21 I/O
A-22 I/O
A-23 I/O
A-24 I/O
A-25 I/O
A-26 I/O
A-27 I/O
A-28 l/O
A-29 I/O
A-30 I/O
A-31 I/O
Signal
Name:
-I/O CH CK
SD7
SD6
SD5
SD4
SD3
SD2
SD1
SD0
-l/O CH RDY
AEN
SA19
SAI 8
SA17
SA16
SA15
SA14
SA13
SA12
SAl 1
SAlO
SA9
SA8
SA7
SA6
SA5
SA4
343
SA2
SAl
SAO
Connector Pinouts D-5
