67
Care and Maintenance
(3) Grasping the front green handle, slide the imaging unit out until
it catches.
(4) Lift up the left green handle. Pull the imaging unit out of the
printer and cover it to protect it from light exposure.
Important:
Do not touch the green surface (the right side) or the black belt (the underside).
Finger prints may affect the print quality.
Safety Caution:
The imaging unit weighs approximately 6.5 kg (14.3 lbs.). Always use the handles
when lifting it.
Cautions:
• Do not expose the imaging unit to artificial light for more than 45 seconds; or you
may damage the unit. Never expose it to direct sunlight.
• Do not leave the printer’s front cover open for an extended period of time (for
example, several hours).
Green surface
Black belt
(3)
(4)
