Care and maintenance – Kyocera FS-5900C User Manual

Page 121

Text mode
Original mode

108

Care and Maintenance

(1)

Raise the output tray and secure it to the printer with adhesive

tape.

(2)

Secure the front cover, the multi-purpose tray and the left side

cover to the printer with adhesive tape.

If you don’t have an option Paper Feeder, go to step 20.

If you have an option Paper Feeder:

(1) Lift the printer up and away from the Paper Feeder.

Safety Caution:

The printer weighs approximately 46.6 kg (103 lbs.) and the Paper Feeder weighs
approximately 14.4 kg (32 lbs.). Observe standard precautions for lifting heavy
objects.

(2) Repack the Paper Feeder in its original shipping box.

Repack any other accessories in the original shipping box. Refer to

the diagram on the next page.

(1)

(2)
