11 GB
J Check before use that the cutting edge is not
blunt and that its mounting is not damaged. Re-
place blunt or damaged cutting tools in a com-
plete set so as not to create a dynamic
unbalance.
J Check the grass box 10 regularly for signs of
wear or deformation.
J Regularly check all nuts and screws for their
tightness, to ensure a faultless operating condi-
tion for the appliance.
J Avoid all collisions between the appliance and
foreign objects (e.g. branches, stones, metal
parts and toys)! Check the grassed area over
and remove all foreign objects!
J Adjust the cutting height of the appliance such
that thecurved blade bar 21 cannot make con-
tact with the ground (unevenness)!
J In the event of a collision with a foreign object
or unusual vibrations, check the appliance for
possible damage and, if need be, arrange for
it to be repaired.
J Never use the appliance with damaged protec-
tive fittings or coverings or deficient protective
equipments such as deflective or grass box
components.
J For collecting the clippings, use the grass box
exclusively 10 !
J Only exchange damaged or worn parts for
original spare parts!
J Only use replacement cutting tools of the same
type as those fitted into the appliance.
J Switch the lawn mower off and remove the
plug when you transport it, cross areas other
than grass or bring the appliance from or to an
area to be mown.
Q
Commissioning
Q
Assembly
c Danger!
J Carry out the assembly ONLY with the appliance
switched off and separated from the power supply!
J Avoid causing damage to the power cable 6
e.g. through squashing it!
Tip!
Lift the appliance from its packaging together
with a second person.
Fasten the steering shaft to the appliance.
j Attach the power cable strain relief 7 to the
lower shaft 9 .
j Place a retaining screw cover 17 on to each of
the tube ends of the lower shaft handle 9 ,
see Fig. A.
j Insert the tube ends of the lower shaft 9 into
the two holes in the housing 14 (see Fig. A).
j Screw them down tightly with the two retaining
screws 15 .
j Now push the the retaining screw covers 17
over each of the retaining screws.
j Fasten the upper shaft 2 with the help of both
connecting screws 8 to the lower shaft 9 .
j Secure the power cable 6 with both cable clips
20 to the upper 2 and lower shafts 9 (see
Fig. C).
Assembling the 10 grass box
j Exactly fit the 2 grass box lower components
together with the grass box upper component.
Begin with the lower components.
The fasteners snap in clearly.
Q
Grass box - fitting / removing
c Danger!
J Switch the appliance off! Wait until the curved
blade bar 21 comes to a complete stop!
Fitting
j Raise up the impact protection flap 11 .
j Attach the grass box 10 to the upper attach-
ment devices 18 and fit it into the clippings
ejection shaft 19 (see Fig. B).
j Lay the impact protection flap 11 onto the
grass box 10 .
General safety advice /Commissioning
