4 Power socket
5 Handle switch
6 Power cable
7 Power cable strain relief
8 Screw connection 2 x
9 Lower shaft handle
10 Grass box with carrying handle
11 Impact protection flap
12 Switch lever for cutting height adjustment
13 Front wheels 2 x
14 Housing with carrying handle and ventilation slits
15 Retaining screw 2 x
16 Rear wheels 2 x
17 Cover for retaining screw 2 x (see Fig. A)
(see Fig. B)
18 Upper attachment device 2 x
19 Clippings ejection shaft
(see Fig. C, F)
20 Cable clip 2 x (see Fig. C)
21 Curved blade bar
22 Securing bolt with washer
Q Items supplied
1 Electric Lawn Mower FSM R1
1 Upper shaft handle
1 Lower shaft handle
1 Grass box upper component
2 Grass box lower components
2 Connecting screws
2 Retaining screws
1 Power cable strain relief
2 Cable clips
2 Covers for retaining screw
1 Operating manual
1 Booklet “Warranty and Service”
Q
Technical Data
Electric Lawn Mower FSM R1
Nominal voltage:
230 V ~ 50 Hz
Nominal power: 1500 W
Cutting width: 40 cm
Cutting height: 20 - 70 mm
Adjustment: synchronised / 6 - levels
Weight: 12 kg approx.
Protection class: II /
Protection type: IPX4 (protected against
spray water from all
directions)
Information on sound levels and
vibration:
A-weighted noise level.
Sound pressure level:
75 dB(A)
Sound power level: 96 dB(A)
Weighted acceleration, typical:
Hand-arm vibration:
4.41 m / s 2
Kompernaß GmbH · D-44867 Bochum · Germany · www.kompernass.com
Date of manufacture: 01-2008
FSM R1
KH3161
230 V ~ 50 Hz
1500 W · ca. 12 kg · IPX4
Q
General safety advice
J Attention! Please read all the instructions
and advice. Failure to observe the instructions
and advice given below may result in electric
shock, fire and / or serious injury.
MAKE SURE THAT YOU KEEP THESE INSTRUC-
TIONS AND SAFETY ADVICE IN A SAFE PLACE.
Introduction / General safety advice
