24 A-61514 September 2004
3. Manually rotate and wipe the feed module rollers with a roller cleaning pad.
4. Inspect the feed module.
If the feed module tires show signs of wear or damage, replace the tires or
the feed module.
5. Remove any dust or debris from the tray area under the feed module and
the front roller cover.
6. Insert the feed module by aligning the pins and pushing it toward the right
to fit it into position.
7. Re-install the front drive roller cover.
8. Go to the next section to clean the drive rollers and transport area.
Cleaning the drive rollers
and transport area 1. Manually rotate and wipe the drive rollers with a roller cleaning pad.
2. Clean any dust or debris in the slots around the drive rollers.
