Kodak A-61514 User Manual
Page 13
10
A-61514 September 2004
Rear
8 Output tray
9 Output tray extender
8
9
Side
1 Output tray extender
2 Output tray
3 IEEE-1394 (FireWire) port
4 Power input
5 Input tray
6 Input tray extender
7 Service LEDs
8 Upper imaging guide access
door (i160 Scanner only)
7
1
2
4
5
6
3
8
Side
1 Red indicator
2 Green indicator
See the section entitled,
“Indicator lights” in the
Troubleshooting section
for more information regarding
these indicators.
1
2
