KITCHENAID KDRP767RSS00 - Manual (Page 2)

OVEN PARTS
2
For Model: KDRP767RSS00
(Stainless Steel)
8186354
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
9758978 Installation
Instructions
9761936 Use & Care Guide
9758979 Tech Sheet
9759441 Conversion
Instructions
3191638 Safer Cooking Tips
9759133 Safer Cooking Tips
9762575 Cook Book
2 4449809 Screw, 8−18 x 3/8
3 4449743 Screw, 8−32 X 3/8
4 9758595 Retainer, Gasket
5 9761101 Pump, Drain (120v)
(Includes Clamps)
6 4450118 Nut,(U−Type Clip)
7 9761161 Top, Chassis
8 4448520 Bumper, Door
9 4452158 Tube, Vent
10 4452163 Lens, Light
11 4448972 Oven Light Assy
4449748 Screw
12 4452164 Bulb, Light
13 Hinge Receiver
4455605 Left Hand
4455606 Right Hand
14 9762238 Frame, Front
15 8300142 Gasket, Door
16 4452152 Bracket, Mounting
17 4452260 Spacer, Foam
18 9758598 Boiler
19 8300184 Support, Insulation
20 9761145 Reservoir
(Includes Clamps)
21 4455510 Bracket, Support
22 9762243 Gasket, Sensor
23 9761107 Sensor, Level
24 9762606 Latch, Motorized
25 4455641 Side, Chassis
26 9761160 Back, Chassis
27 Liner, Oven
(Not serviceable)
29 4455636 Sensor
30 4449154 Screw, 8−32 x .440
31 4449040 Screw, 8−18 x 3/8
32 3196176 Screw (2)
33 9758597 Orifice, Boiler
34 9758596 Cover, Orifice
Boiler
35 9762138 Hose, (Blue)
(Pump to Outlet)
36 9762139 Hose (Gray)
(Boiler to Pump)
37 4450249 Thermostat (TOD)
(150c) SPST
38 9761154 Hose (Green)
(Boil’r to Resv’r)
39 9761147 Clamp
40 9761146 Clamp
41 9762844 Screw
43 8300965 Base, Chassis
50 9758583 Cover, Back
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
8300158 Insulation, Wrap
8300159 Insulation, Back
