KITCHENAID KDRP767RSS00 - Manual (Page 10)

OPTIONAL PARTS
10
For Model: KDRP767RSS00
(Stainless Steel)
8186354
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
SPLICING WIRES−−25FT.
LENGTH
242828 Wire (12 Ga.
150 c Black)
242820 Wire (14 Ga.
150 c Black)
242821 Wire (14 Ga.
150 c Blue)
242822 Wire (14 Ga.
150 c Brown)
242830 Wire (14 Ga.
200 c Brown)
242823 Wire (14 Ga.
150 c Green)
242824 Wire (14 Ga.
150 c Orange)
242829 Wire (12 Ga.
150 c Red)
242825 Wire (14 Ga.
150 c Red)
242831 Wire (14 Ga.
200 c Red)
242826 Wire (14 Ga.
150 c White)
242827 Wire (14 Ga.
150 c Yellow)
242832 Wire (14 Ga.
200 c Yellow)
WIRING HARNESS PARTS
9758957 Harness, Sensor
9758951 Harness, Wire
(Main)
3196896 Clip, Wire
4456628 Harness, Wire
(Ignitor 39")
4456627 Harness, Wire
(Ignitor 28")
9761098 Harness, Signal
9761106 Wire, Jumper
(Oven Light)
9762508 Harness, Wire
(DSI, 36", Steam)
3191506 Bushing, Conduit
1129449 Bushing
8301668 Conduit
4449809 Screw
112432 Nut
4450800 Screw, Ground
ADHESIVE
591014 Adhesive
Loctite (1/3 oz.)
482338 Sealer, Silastic
(3 oz.)
4453192 Seal, Ribbon
Cable
4453191 Seal, Access
Panel
2261590 Cleaner, S.steel
Miscellaneous
8301282 Conv. Kit (LP)
4453141 Bracket,
Anti−Tip (1")
4453202 Bracket,
Anti−Tip (1 3/4")
