3.2 10BASE-T Switched Ports
The individual RJ-45 connectors of Port #1 to Port #7 are defined as X
type connectors and have fixed pin assignments as follows:
The following table lists the devices to which Port #1 to #7 can connect :
Device connected Cable used
Computer 10BASE-T port Cat. 3, 5 straight UTP
10BASE-T hub port (I type) Cat. 3, 5 straight UTP
10BASE-T switched port (I type) Cat. 3, 5 straight UTP
Port #8 has a configurable RJ-45 connector and its pin assignments are
determined according to the setting of the crossover switch next to the RJ-
45 connector as follows:
12
