Attaching the imprinter board and cable – Kodak i250 User Manual
Page 42
A-61167 September 2002
C-3
9. Lift up the circuit board cover and remove it.
10. Go to the next section to attach the imprinter board and cable.
Attaching the Imprinter
Board and Cable
The imprinter board is first attached to a mounting bracket which is connected
to the main control board, then the imprinter cable is plugged in.
IMPORTANT: Use proper precautions to avoid static when you install the
imprinter card.
1. Place the imprinter board on the circuit board mounting bracket.
