4. Applications
4.1 Application in Industrial Networks
The following figure illustrates an application example in an industrial network. Four devices are
cascaded by fiber cables.
4.2 Copper to Fiber Bridging Media Converter Application
4.3 Bridging Multimode to Single Mode Fiber Converter Application
18/20
