75
Signal Pin no. TV
Audio right output 1 X
Audio right input 2
Audio left output 3 X
Audio earth 4 X
Blue earth 5 X
Audio left input 6
Blue signal 7 X
Switching voltage 8 X
Green earth 9 X
Data signal 10
Green signal 11 X
Data signal 12
Red earth 13 X
Data earth 14
Red signal (C) 15 X
Blanking signal 16 X
Video earth 17 X
Blanking signal earth 18 X
Video output (FBAS/Y) 19 X
Video input 20
Connector shield 21 X
The Scart socket can be switched between VHS and S-VHS. The switch is made by selecting
“Mainmenu”, “Settings”, “TV, Video and Audio”.
For VHS (RGB): The red signal is connected to terminal 15, the composite colour output to terminal 19.
For S-VHS (C/Y): The Y output is connected to pin 19, the C output to pin 15.
SCART SOCKET ASSIGNMENT
VHS/S-VHS SWITCHING
TECHNICAL APPENDIX
