74
Type UFS 902si UFS 902sw
Order no./colour 20210129/silver 20210130/black
RF range
Sat IF band MHz 950-2150
Input level band dBµV 44-83
Reception threshold (EB/NO) dB
TV system video
Modulation, FEC, demultiplexer DVB-S/DVB-S2 standard
Video resolution CCIR 601 (720 x 576 lines), 576p, 720p, 1080i
Video decoding MPEG-2-, MPEG-4-compatible
Input data rate MSymb/s 2-45
Bit rate MBit/s
Frequency range MHz
Output voltage V
pp
S/N dB > 53
TV system audio
Decoding AC 3, MPEG-4 (AAC-HE), MPEG-1, layer 1, 2 and 3
Sampling rate kHz 32/44.1/48
Frequency range kHz
Output voltage mV
pp
S/N dB > 65
Memory
Flash-RAM/SDRAM MB 32/128
Processor clock speed MHz 200
Power supply
Mains voltage V/Hz 100-240/50-60
Power consumption (power/standby) W < 26/1
LNB supply (horiz./vert.) V/mA 14/18; max. 400
Control signal kHz 22; ToneBurst; DiSEqC TM 1.0
Connections
Sat IF input/output 2 x F sockets
TV/VCR connection 1 x Scart sockets
Video output (analogue) 3 x Cinch socket (YPbPr)/1 x Cinch socket
Video/audio output (digital) 1 x HDMI
Audio output (analogue/digital) 2 x Cinch sockets/SPDIF
Data interface
Common Interface For 1 CA module
USB 1 x 2.0
RS 232 1
General
Ambient temperature °C Max. + 5 to + 40
Unit dimensions (W x H x D) mm 342 x 67 x 273
Weight kg < 3
TECHNICAL APPENDIX
