69
SERVICE MENU
Also note the bars at the bottom
of the on-screen display! These
provide information on what to do
next.
Updating software
If new software is available (but only then), use the buttons (No/Yes) to select whether you
wish to load the new software that is available. If you are unsure whether you wish to load the new
software, you can initially set the reply to “No”. If you do agree to the changes, you can then proceed to
download the software.
Updating channel list
If a new channel list is available (but only then), use the buttons (No/Yes) to select whether you
wish to load the new channel list that is available.
When you have made your settings, use the buttons to select “Start Update” and press the
button to start the update.
The following display appears (example):
