INTRODUCTION
Turbo 120 01/11
Introduction Section 2-3
© 2011 Alamo Group Inc.
INTRODUCTION
The Rhino Turbo 120 Rotary Mower is designed for medium duty applications such as weed, grass, corn
stalks, and light brush to 3" diameter. These mowers are single spindle with two free-swinging blades. Free
swinging blades reduce the shock of impact when a stationary object is hit. Additional protection is provided by
a slip clutch on the gearbox input shaft. A round blade holder allows the mower to “ride over” stumps and
similar immovable objects. These Mowers are attached to the tractor using 3-point Cat II or III standard or
quick hitches or pull hitches. Standard equipment includes driveline shields, clutch shields and front and rear
discharge shields.
EQUIPMENT SPECIFICATIONS
Cutting Width
120”
Blade Tip Speed
Transport Width
127”
540 RPM
16063 FPM
Overall Width
127”
1000 RPM
16167 FPM
Overall Length
116” (Lift) 156” (Pull)
Gearbox Rating
Cutting Height (Min)
1-12”
Center
210 HP
HP Required
80 HP-(Lift) 55 HP-(Pull/Semi)
Outboard
205 HP
Cutting Capacity
3”
Limited Warranty
5 Year
Weight
3210 lbs (Pull).
2586 lbs (Lift)
Driveline Size
CAT 4
2820 lbs (Semi-mount)
Limited Warranty
1 Year
Tongue Weight
1180 lbs
