D389 1 decal multi hazard, D390 1 decal pull type unit hazards, D388 1 decal driveline hazards – Servis-Rhino TURBO120 User Manual
Page 29: 00756005 2** danger rotating d/l entanglement, D137 1 instruct ccw blade rotation, D138 1 instruct cw blade rotation, D454 1 warning crushing hazard (decal under deck), 00771283 3 instruct 5 year gearbox warranty, D608 2 warning blade timing, 99102 1 logo rhino
SAFETY
Turbo 120 01/11
Safety Section 1-19
© 2011 Alamo Group Inc.
SAFETY
ITEM
PART NO.
QTY
LEVEL
DESCRIPTION
1.
D389
1
DECAL
Multi Hazard
2.
D390
1
DECAL
Pull Type Unit Hazards
3.
D388
1
DECAL
Driveline Hazards
4.
00756004
3
DANGER
D/L Shield Missing. Do Not Operate
5.
00756005
2**
DANGER
Rotating D/L Entanglement
6.
D137
1
INSTRUCT
CCW Blade Rotation
7.
D138
1
INSTRUCT
CW Blade Rotation
8.
D454
1
WARNING
Crushing Hazard (Decal under Deck)
9.
00771283
3
INSTRUCT
5 Year Gearbox Warranty
10.
D608
2
WARNING
Blade Timing
11.
99102
1
LOGO
Rhino
12.
D303
2
LG. NAME
Rhino Type (4-3/8 x 16-3/4)
13.
00785615
2
LG. NAME
TURBO 120
14.
00785514
1
SM. NAME
TURBO 120
15.
D302
2
LOGO
Rhino Logo (4-7/8 x 6-1/2)
16.
03200347
1
REFLECTOR
SMV Sign
17.
00760657
1
IMPORTANT
Rhino Genuine Parts, Rotary Mower
18.
nfs
1
SER PLT
Serial Number Plate
19.
D401
1
INSTRUCT
1000 RPM
20.
1458392
2
REFLECTOR
Red Reflectors
21.
1458393
2
REFLECTOR
Amber Reflectors
22.
00776031
1
Canister, Operator’s Manual
23.
00778586C
1
Operator’s Manual
24.
10058000
3
Bolt
25.
00024100
6
Flatwasher
26.
02959924
3
Locknut
27.
D518
1
WARNING
Jack Positioning
28.
00785538
1
INFORMATION
Turbo Dome Deck
29.
D614
3
DANGER
Thrown Object Shield Missing
30.
D534
2
IMPORTANT
Torque Blade Bolts 600 lbs.
31.
D629
1
INFORMATION
Lube Chart
** Provided by Driveline Manufacturer
DECAL SHEETS
Dual Spindle Decal Sheet D442
Turbo 120 Decal Sheet D475
