P AGE 46 J UNE 17, 2008 D OCUMENT : 3650H-02DSR
SSD-H XXX (I)-3650 D ATA S HEET ATA C OMMAND B LOCK AND S ET D ESCRIPTION
Set Features — EFh
The Set Features command allows the host to configure the feature set of the
device according to the attributes listed in
Table 48 .
On power-up or following a hardware reset, the device is set to the default
mode 81h.
Table 47: Set Features — EFh
Register D
7
D
6
D
5
D
4
D
3
D
2
D
1
D
0
Feature Feature
Sector Count X
Sector Number X
Cylinder Low X
Cylinder High X
Drive Head X X X Drive X
Command EFh
Table 48: Set Features’ Attributes
Feature Operation
01h Enable 8-bit data transfer
66h Disable reverting to power on defaults
81h Disable 8-bit data transfer
BBh 4 bytes of data apply on Read/Write Long commands
CCh Enable revert to power on defaults
