ATA R
EGISTERS
A
LTERNATE
S
TATUS
R
EGISTER
The Alternate Status register is a read-only register indicating the status of the
device, following the previous ATA command. See
for specific details.
Table 26: Alternate Status Register
Operation
D
7
D
6
D
5
D
4
D
3
D
2
D
1
D
0
Read/Write
BSY
DRDY
DWF
DSC DRQ CORR
IDX
ERR
Default Value
0
0
0
0
0
0
0
0
