39
R
Section 8
Ref. No. Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
483957
48
609
462069
483609
48717
483904
04010-01
04019-01
48028-05
483872
483960
04017-19
04019-03
Switch, PTO 10 Amp
Keyswitch
Key Chain w/Keys
Key w/Shroud
Switch
Throttle Cable
Screw, #10-32 x 1/2"
Nut, #10-32
Cable Tie
Wire Harness, Handle Bar
Wire Harness, Engine Deck
Bolt, Serrated Flange 5/16-18 x 1-1/2"
Nut, Serrated Flange 5/16-18
ELECTRICAL SYSTEM AND THROTTLE CONTROL
