Section 8
36" CUTTER DECk
Ref.
No.
Part No. Description
1 462150 Cutter Deck Weldment w/Decals
2 04112-06 Nut, 3/4-16 Spiral Lock
3 04063-01 Key, 1/4 x 1/4 x 1-1/4"
4 04021-09 Nut, Elastic Stop 3/8-16
5 04043-04 Flatwasher, 3/8-.391 x .938 x .105 HD
6 424615 Bracket, Belt Guide
7 424367 Dust Shield
8 483324 Pulley, 5.73" Dia.
9 481880 Belt, Deck Drive
10 483851 Pulley, 5" Idler
11 04041-11 Flatwasher, 3/8-.406 x 1-1/2"
12 483453-03 Bearing
13 462190 Idler Arm Assembly (incl. #12)
14 04001-62 Bolt, Hex Head 3/8-16 x 3-1/4"
15 43708 Pivot, Idler
16 04001-46 Bolt, Hex Head 3/8-16 x 2-1/4"
17 483379 Bearing
18 43703 Spacer, Bearing
19 04019-04 Nut, Serrated Flange 3/8-16
20 04001-136 Bolt, Hex Head 3/8-16 x 1-1/2" Gr.8
21 483375 Spring, Deck Idler
22 04041-38 Flatwasher, 3/8-.406 x 2-1/4 x .187
23 04001-51 Bolt, Hex Head 3/8-16 x 3-3/4"
24 04001-175 Bolt, Hex Head 5/16-18 x 1-1/2" Gr.8
25 04021-22 Nut, Elastic Stop 5/16-18
26 04030-03 Lockwasher, 5/16" Spring
27 481707 Cutter Blade, 18"
28 04043-06 Flatwasher, 5/8-.688 x 1-3/4 x .134 HD
29 04030-07 Lockwasher, 1/2" Spring
30 04001-121 Bolt, Hex Head 5/8-11 x 1-1/2"
31 461950 Spindle Assembly
32 483304 Debris Shield
33 483303 Bearing
34 43693 Spacer, Bearing
35 462014 Spindle Housing Assembly (incl. #33 & #34)
36 43694 Protector, Bearing
37 43695 Shaft, Spindle
38 04021-10 Nut, Elastic Stop 5/16-18
39 04001-12 Bolt, Hex Head 5/16-18 x 1-3/4"
40 04001-154 Bolt, Hex Head 5/16-18 x 4-3/4"
41 482245 Spring, Discharge Chute
42 462031 Discharge Chute Assembly
