33
R
Section 8
CUTTER DECk CONTROLS
1 462183 Belt Cover, SFW w/Decals
2 462181 Frame Weldment w/Decals
3 04009-13 Bolt, Shoulder 1/2 x 1-1/2"
4 425023 Pusharm
5 43041 Spacer
6 04009-10 Bolt, Shoulder 1/2 x 2-3/4"
7 04019-04 Nut, Serrated Flange 3/8-16
8 04021-09 Nut, Elastic Stop 3/8-16
9 04043-04 Flatwasher, 3/8-.391 x .938 x .105 HD
10 425076 Mounting Bracket, Height Adjustment Rear
11 425077 Mounting Bracket, Height Adjustment Front
12 43572 Spacer
13 462188 Bracket, Deck Lift Height Adjustment - LH w/Decal
462189 Bracket, Deck Lift Height Adjustment - RH w/Decal
14 04001-46 Bolt, Hex Head 3/8-16 x 2-1/4"
15 04001-31 Bolt, Hex Head 3/8-16 x 2-1/2"
16 04062-01 Hair Pin Cotter, .094 x 1.62"
17 04067-13 Pin, Ring 3/8 x 2-1/2"
18 481428 Grip
19 483922 Caster Wheel Assembly, 9 x 3.5-4
20 48114-03 Grease Fitting, 45 Degree 1/4-28
21 481770 Bearing, Oilite
22 481769 Bearing, Roller
23 48
3981
Tire Only, Caster Wheel
48
3921 Rim Only
24 43022 Sleeve, Caster Wheel
25 04001-37 Bolt, Hex Head 1/2-13 x 5-1/2"
26 04021-07 Nut, Elastic Stop 1/2-13
27 45006 Caster Yoke Weldment
28 483453-
17
Bearing
29 04066-01 Quick Pin
30 04029-04 Wing Nut, 3/8" Plastic Small
31 04024-02 Nut, Push-On 3/8"
32 04003-23 Bolt, Carriage 3/8-16 x 1"
Ref.
No.
Part No. Description
