Section 8
HANDLE ASSEMBLY
Ref.
No.
Part No.
Description
Ref.
No.
Part No.
Description
1
462187
Handle Weldment w/Decals
2
452039
Operator Presence Handle, LH
452040
Operator Presence Handle, RH
3
483941
Spring, Operator Presence
4
04001-13
Bolt, Hex Head 5/16-18 x 2-3/4"
5
04001-53
Bolt, Hex Head 5/16-18 x 2-1/2"
6
483161
Plug, Handle Bar
7
04032-01
Washer, Curved Spring
8
04021-10
Nut, Elastic Stop 5/16-18
9
04040-15
Flatwasher, 5/16-.375 x .875 x .083
10
04001-17
Bolt, Hex Head 5/16-18 x 2"
11
461241
Neutral Latch Assembly, LH
461242
Neutral Latch Assembly, RH
12
483870
Lever, Steering Brake
13
04062-02
Hair Pin Cotter
14
44140
Rod, Steering Control
15
04062-01
Hair Pin Cotter
16
43032
Swivel Joint
17
462173
Idler Bracket Assembly, RH
462172
Idler Bracket Assembly, LH
18
483453-18
Bearing
19
43768
Sleeve
20
04019-04
Nut, Serrated Flange 3/8-16
21
04021-09
Nut, Elastic Stop 3/8-16
22
421360
Belt Guard
23
04017-28
Bolt, Serrated Flange 3/8-16 x 1-1/4"
24
48755
Spring
25
04004-17
Stud, 3/8-16 x 5"
26
43282
Spacer
27
483820
Pulley, Idler 5"
28
462171
Lever Weldment, Brake w/Bearing
29
483453-19
Bearing
30
04009-09
Bolt, Shoulder 1/2 x 1"
31
45093
Link Weldment, Brake
32
04001-45
Bolt, Hex Head 3/8-16 x 2"
33
48210
Brake Band Assembly
34
42254
Link, Brake
35
04024-01
Nut, Push-On
36
44177
Rod, Brake
37
04001-62
Bolt, Hex Head 3/8-16 x 3-1/4"
38
04001-09
Bolt, Hex Head 5/16-18 x 1"
39
04030-03
Lockwasher, 5/16" Spring
40
04040-15
Flatwasher, 5/16-.375 x .875 x .083
41
04001-23
Bolt, Hex Head 3/8-16 x 4-1/2"
42
04019-02
Nut, Serrated Flange 1/4-20
43
04050-09
Retaining Ring, 5/8" Ext.
44
48224
Bearing, Jackshaft
45
48223
Flange, Jackshaft Bearing
46
04017-05
Bolt, Serrated Flange 1/4-20 x 3/4"
47
43801
Spacer, Jackshaft
48
04012-04
Set Screw, Hex Socket 5/16-18
49
483821
Pulley, Jackshaft 3.25 OD x .625 Bore
50
483814
Belt, Wheel Drive
51
48059-01
Clamp, 1/4" ID Fuel Hose
52
483617
Fuel Hose, 1/4" ID (order by inch)
53
483747
Valve, Fuel Shutoff w/Screen
54
482571
Bushing, .56 Dia. Viton
55
461729
Fuel Tank Assembly (incl. #53 & #54)
56
483792
Cap, Fuel Tank
57
04017-17
Bolt, Serrated Flange 5/16-18 x 1"
58
461163
Shift Lever Extension w/Grip
59
481839
Grip, Shift Handle
60
48028-05
Cable Tie
61
422279
Shift Lever
62
04041-07
Flatwasher, 3/8-.391 x .938 x .105
63
04019-03
Nut, Serrated Flange 5/16-18
64
04020-14
Nut, 3/8-24 UNF
65
04017-27
Bolt, Serrated Flange 3/8-16 x 1"
66
483646
Choke Control
