English _1
English
ZONe seT
You can set the north direction and the zone coverage.
For selecting and saving each menu item, refer to “How to use the keyboard controller”. (page 20)
Select
Set to .
Set the north direction using the joystick
and press [ENTER].
SET NORTH : In SET NORTH, press
[ENTER] to set the north direction
which will be the reference for all other
directions.
Set to .
When the screen
appears, select a number.
When the screen
appears, set the and
.
For entering the name, refer to “ CAMERA ID”.
(page 24)
POSITION : Sets the left/right boundaries
of the zone.
1.
2.
3.

4.
5.
6.


 ZONE SET 
AZIMUTH OFF
ZONE AREA SET OFF
 MAIN MENU 
PROFILE
CAMERA SET
INTELLIGENCE
PRIVACY ZONE
PRESET
AUTO SET
ZONE SET
ALARM SET
CLOCK SET
OTHER SET
ZONE AREA MAP
1 2 3 4
5 6 7 8
